Chimney Scaffolding

Chimney Scaffolding Specification

Color
Silver / Blue / Custom

Sleeve size
60 mm standard sleeve

Features
Heavy Duty, Corrosion Resistant, Easy to Assemble, Stable Structure

Technique
Welded Frame Construction

Constitute
Complete Modular System

Pin
Lock Pin Available for Frame Joints

Product Type
Chimney Scaffolding

Material
Heavy Duty Mild Steel (MS) Pipes

Components
Vertical Frames, Horizontal Braces, Platforms, Base Plates, Guard Rails, Toe Boards, Adjustable Jacks

Diameter
Standard tube diameter 48.3 mm

Width
Approx. 1.20 m

Length
Frame Length approx. 2.0 m

Height
Customizable up to 30 m or as required

Thickness
3.2 mm (main tubes)

Platform Loading Capacity
250 kg/m

Surface Treatment
Hot Dip Galvanized / Painted

Size
Standard and Custom Sizes

Climbing Access
Ladder integrated/on request

Base Plate Size
150 mm x 150 mm

Connection Type
Prefabricated Joint Couplers

Guard Rail Height
1000 mm from platform

Adjustable Height Range
150 mm to 900 mm

Weather Resistance
High - suitable for outdoor use

Transport and Storage
Stackable Components for Compact Handling

Working Platform Width
600 mm / 900 mm (standard options)

Chimney Scaffolding Trade Information

Minimum Order Quantity
1 Unit

FOB Port
Mundra

Payment Terms
Cash on Delivery (COD), Cheque, Cash Advance (CA)

Supply Ability
1 Unit Per Day

Delivery Time
1 Week

Packaging Details
As per Requirement

Main Export Market(s)
Africa, Middle East, Asia

Main Domestic Market
All India

Certifications
CE Mark,ISO9001:2008 certification

About Chimney Scaffolding

Encouraged by the immense support from our team, we are able to manufacture, supply and export Chimney Scaffolding. Made of supreme quality raw materials that are supposed to be the best in the market, these products provide accurate and optimum performance. Checked by our team of skilled quality analyzers, these products have flawless and unmatched quality. These products are used in various construction sites for installing different chimney fixtures. Chimney Scaffolding is delivered to the clients in a timely manner owing to our expert logistics team.

Features:

Low maintenance
High durability
Better functioning
Resistance against corrosion

Other details:

Balaji Industries is a leading manufacturer of various kind of suspended platform. We have wide experience of manufacturing inside & outside chimney platforms. Inside chimney gondola's size is adjustable and can be minimized from 1mtrs to 8mtrs dia. We can customize our cradles as per the design of chimney. We have installed our platforms on chimney upto 175 mtrs height. Please contact us for further details.

Robust and Modular Design

Constructed with welded frame technology and high-strength mild steel, this scaffolding system features a secure modular structure. Prefabricated joint couplers and lock pins ensure quick assembly and strong joints. The adjustable base plates and jacks provide precise leveling and stability, making it suitable for customized setups up to 30 meters high.

Safety and Accessibility Focused

For superior onsite protection, the system is equipped with 1000 mm guard rails, toe boards, and optional integrated ladders for safe climbing access. Its wide working platforms (600 mm/900 mm) allow for comfortable movement and tool placement, meeting stringent safety standards for height work.

Weather and Transport Ready

Designed for outdoor applications, the scaffolds hot-dip galvanized or painted finish guards against corrosion, ensuring long-term durability. All components are engineered to be stackable and compact for effortless transport and efficient storage in confined environments.

FAQs of Chimney Scaffolding:

Q: How is the chimney scaffolding system assembled on site?

A: The scaffolding utilizes prefabricated joint couplers and welded frame construction, allowing for quick, secure assembly. Each componentvertical frames, horizontal braces, platformsis connected using lock pins and adjustable jacks, ensuring both strength and adaptability during installation.

Q: What are the main benefits of using this modular scaffolding system?

A: Key benefits include its heavy-duty mild steel construction, high weather resistance, customizable height (up to 30 meters), and ease of assembly. The systems modularity enables flexibility for various chimney and site requirements while complying with strict safety standards.

Q: When is it ideal to use this scaffolding system?

A: This system is best used during construction, repair, or maintenance work on chimneys and similar high structures, especially when safe, stable, and customizable access is needed under outdoor weather conditions.

Q: Where can the scaffolding be deployed?

A: It is suitable for industrial sites, construction projects, and maintenance tasks, both indoors and outdoors, throughout India and internationally. Its corrosion-resistant finish makes it particularly appropriate for prolonged outdoor stays.

Q: What is the process for adjusting the platform height?

A: Platform height is altered using adjustable base plates and jacks, which provide fine-tuned elevation from 150 mm to 900 mm increments. This flexibility ensures optimal working levels for different tasks and operator preferences.

Q: How is safety enhanced during usage?

A: Safety is prioritized with 1000 mm high guard rails, toe boards, and optional integrated ladders. Non-slip platforms and a stable base ensure secure footing, while lock pins provide sturdy connections to prevent accidental dislodgement.
